The CNDLive D1 4K HDMI/SDI Video Decoder is a cutting-edge solution for decoding high-resolution video streams. With support for 4K UHD decoding, this device delivers superior video quality, making it ideal for professional video applications. Equipped with both HDMI and SDI outputs, the D1 decoder offers seamless compatibility with various display systems and workflows, ensuring flexibility for broadcasters, live event producers, and AV professionals.



Technical Specifications

Video Output: HDMI 2.0 and 3G-SDI
Supported Resolutions: Up to 3840x2160 (4K UHD) at 60fps
Video Decoding: H.264/H.265
Audio Output: Embedded audio via HDMI/SDI; 3.5mm stereo audio output
Network: 2×/100M/1000M (With 1xPoE）
Supported Protocols: NDI High Bandwidth, NDI|HX2, SRT, RTMP, RTMPS, HLS, TS over UDP, RTSP, RTMP server
Control Interface: Web-based GUI for easy configuration
Dimensions: 180mm x 115mm x 50mm
Power Supply: DC 12V 2A
Operating Temperature: -10°C to 50°C
Weight: 850g

Applications

The CNDLive D1 4K Decoder is well-suited for:

Broadcasting: Deliver high-quality decoded video signals to TV stations and broadcast systems.
Live Event Production: Receive video feeds for playback on large screens or streaming to online platforms.
Corporate and Enterprise Streaming: Decode live streams for presentations, conferences, and internal communications.
Digital Signage: Use in advertising and information displays that require high-definition video.
Education: Enable decoding of video lectures and streaming sessions for seamless remote learning experiences.

The CNDLive D1 4K HDMI/SDI Decoder is an essential tool for any professional AV setup, offering flexibility, high performance, and ease of integration to meet the demands of modern video workflows.
